Schneider Electric Conext SW AC Power Distribution Panel

Schneider Electric 865-1017 Conext SW AC Power Distribution Panel RNW8651017

The ConextTM SW Power Distribution Panels are pre-wired out of the box and labeled to support the integration of Conext SW inverter/chargers with a Conext MPPT Solar Charge Controller, battery bank and load centers. Designed to save installers significant time, effort and costs on every installation, the Distribution Panels offer excellent value when compared to customized options.

The AC Breaker Panel (120/240V) is pre-wired for quick installation with a single Conext SW and ensures a safe and code compliant connection to a secondary AC distribution panel or directly to AC loads. The AC Breaker Panel accommodates split phase output from Conext SW. The AC Breaker Panel featres seven breaker spots for inverter AC input, AC output, interlocked AC bypass and GFCI breakers. There is provisioning for a single DIN mounted surge arrestor and multiple inline surge arrestors. Three 30A breakers are included. Dual Conext SW installations can be accommodated with the addition of the AC Breaker Kit for Stacked Conext SW.

Why choose Conext SW Power Distribution Panels

• Higher return on investment
  • ntegrate SW inverter/chargers and MPPT Solar Charge Controllers with a single battery bank
  • Repeatable standard installation that saves time and money
• Flexible
  • Additional DC and AC breaker slots available for expanded capacity
  • Key holes available on side of DC panel for integrating MPPT 60 Solar Charge Controller
  • Use AC distribution panels as optional load centers
• Easy to service
  • Breaker configuration allows SW inverter/chargers to be AC bypassed for servicing
  • Removable front cover allows for visual inspection

What's Included

• 1 x Distribution Panel Box
• 1 x Distribution Panel Cover
• 2 x Double-pole 30-amp AC Breaker (bundled)
• 1 x Double-pole 60-amp AC Breaker
• 4 x Jumper Bar (pre-installed)
• 1 x Handle Interlock Device (pre-installed)
• 6 x 10 AWG AC Wire (black, pre-wired)
• 2 x 10 AWG AC Wire (red, pre-wired)
• 1 x 10 AWG AC Wire (white, pre-wired)
• 1 x 12 AWG Ground Wire (green, pre-wired)
• 4 x Terminal buses (one each - L1, L2, Ground, Neutral)
• 1 x DIN Rail
• Expansion positions available for up to 8 x single pole AC breakers or 4 x double pole AC breakers
