Stellavolta: Morningstar PS-15 ProStar Solar Controller 15A

Description

Morningstar Corporation Logo Stella Price

Morningstar PS-15 ProStar Solar Controller 15A for 12/24VDC Battery Bank. Add to cart to see our every day low Stellar Price!

Morningstar’s third generation ProStar is the world’s leading mid-range solar controller for both professional and consumer applications.

Key Features and Benefits

Estimated 15 year life
Compliance with IEC 62109
PWM series battery charging (not shunt)
8 dip switches to adjust battery charging and other settings
High resolution graphical meter to adjust settings and display logged data
RJ-11 MeterBus port for serial MODBUS data or to add a remote meter
Up to 256 days of data logging
Dusk-to-dawn and advanced programmable lighting control
Protective terminal cover
Enhanced surge rating for heavy DC loads
Self-diagnostics
Slow switching mode to eliminate system noise at telecom sites
Parallel for up to 300 amps
Temperature compensated charging
Tropicalization
No switching or measurement in the grounded leg
100% solid state
Very low voltage drops
Current compensated low voltage disconnect (LVD)
LED’s to indicate battery status and faults
Capable of 25% overloads
Remote battery voltage sense terminals

Morningstar String Calculator
The Morningstar String Calculator will help you decide how many PV modules you may use in series and parallel with a Morningstar charge controller.

Other brands survive harsh conditions. Morningstar thrives in them.

With more than 25 years of experience and well over four million products in over 100 countries – most of them still in operation – Morningstar has truly earned its reputation for building the “world’s leading solar controllers.” At Morningstar, the word “reliability” means a lot more than a marketing adjective. Morningstar’s employee-owned culture works hard to maintain the lowest hardware failure rate in the industry, because our own reputations literally ship with every product.

That’s why system designers of the most mission-critical solar energy installations around the world insist on Morningstar components, and why you should too on your next project. From mineral mines in South America to telecom repeater stations in Canada, from gas wells in the Middle East to mountain peaks in Nepal, Morningstar technology and legendary quality make the difference between success and failure – and make renewable energy a practical, cost-effective, and long-term solution.

FAQs

Will the ProStar Charge Controller automatically cut power to the load if the battery voltage gets low, to prevent over discharge of the battery?
Yes, the Morningstar PS-15M offers Low Voltage Disconnect (LVD). If the battery discharges to the LVD set-point, the load will disconnect and a solid red Battery Status LED indication will be displayed.

Attachments

Skid mounted 520W solar power systems power satellite terminals used for pipeline monitoring and control in North Texas.

Morningstar Application Example A

Morningstar's ProStar-15M solar controller is a component of the award-winning WE CARE Solar Suitcase. The suitcase is a portable power unit that provides health workers in remote locations with highly efficient medical lighting and power for mobile communication, computers and medical devices. Photo courtesy of Dr. Laura Stachel, We Care Solar.

Morningstar Application Example B

Home system application, illumination, refrigerator using a Morningstar ProStar 30M. Customer is OTTOWATT di Fabio Ottavi. Courtesy of Heliant SRL.

Morningstar Application Example C

Electrification of three schools in Benin utilizing a ProStar solar controller.

Morningstar Application Example D
